ACM Series 100~ 1200kVA Modular UPS
Power range
100~ 1200kVA
Operation
3P/3P,Online double conversion
Characteristics
- Fully digital control, flexible and robust.
- 10 inch touch LCD, with IoT functions.
- High reliability and environmental adaptability, with protection of components level.
- Supports battery connection without Neutral.
- Maximum capacity of up to 3.2MW,the ideal choice for large data centers.
Applications
Government
Finance
IT
Education
Transportation
Broadcasting
Medical
Energy
Data Parameters
Rate Power | 600kVA | 800kVA | 1200kVA | ||||
Main input | Input | 3P5W (3P+N+PE) | |||||
| Rate Voltage | 380/400/415VAC(L-L) | ||||||
| Rate Freq. | 50/60Hz | ||||||
| Input PF | >0.99 | ||||||
| Current distortion | THDi<2% | ||||||
| Voltage range | 304~478VAC(L-L)full load ; 304~228VAC (L-L) power derate from 100% to 50% | ||||||
| Freq. range | 40-70Hz | ||||||
Battery | Rate voltage | 3 wires: ±240VDC / 2 wires: 480VDC | |||||
| Charging capacity | Max. 15%*Pout | ||||||
| Charging accuracy | ±1% | ||||||
Bypass | Rate voltage | 380/400/415VAC(L-L) | |||||
| Voltage range | Range: -40%- +25% , Settable, default -20% +15% | ||||||
| Overload | 110%, long time operation 110%< load<125%, 10 mins 125%<load<150%,1 min >150%,1s | ||||||
Inverter | Rate voltage | 380/400/415VAC(L-L) | |||||
| Rate Freq. | 50/60Hz | ||||||
| Output PF | 1 | ||||||
| Voltage accuracy | ±1.0% | ||||||
| Output THDu | <1%(linear load),<3% (non-linear load according to IEC 62040-3) | ||||||
| Overlord | 110%,1 hour ; 125%,10 mins ; 150%,1 min ; >150%,200ms | ||||||
| Frequency accuracy | 0.1% | ||||||
| Synchronize window | Settable , ±0.5Hz-±5Hz , default ±3Hz | ||||||
| Slew rate | Settable , 0.5Hz/S-3Hz/S , default 0.5Hz/S | ||||||
| Crest factor | 3:1 | ||||||
| Phase Accuracy | 120°±0.5° | ||||||
System | Efficiency | Up to 97% | |||||
| Display | LED + 10 inch touch LCD | ||||||
| Certification- Safety | IEC62040-1, IEC60950-1 | ||||||
| Certification- EMS | IEC62040-2 ; IEC61000-4-2(ESD) ; IEC61000-4-3(RS) ; IEC61000-4-4 (EFT) ; IEC61000-4-5 (Surge) | ||||||
| IP degree | IP20 | ||||||
| Configuration | USB, RS232, RS485, Dry contact, Cold start, Air filter | ||||||
| Option | SNMP card, AS400 card, Parallel kit, SPD | ||||||
| Environment | 0-40℃ (operation) ; -25℃ ~70℃ (storage) ; 0-95% (Humidity, non-condensing ) | ||||||
| Noise(dB)(1 meter) | 72dB @ 100% load, 68dB @ 45% load | ||||||
Dimension | Cabinet(W*D*H)mm | 800*1000*2000 | 1200*1100*2000 | ||||
| Module(W*D*H)mm | 475*705*140 | ||||||
Weight(kg) | Cabinet | 380 | 390 | 624 | |||
| Module | 47 | ||||||
Power Module rated capacity | 100KW | ||||||
