Matinal AC5000 Series Modular Data Center
Matinal AC5000is a prefabricated modular data center solution for edge facilities, branch sites, equipment rooms, and small-to-medium data centers.
It integrates IT cabinets, UPS, power distribution, battery backup, precision cooling, monitoring, access control, and emergency ventilation within one unified system.
Flexible expansion: Supports 1–15 cabinetsas standard and up to 30 cabinetswith customized power distribution.
Integrated power: Standard configurations support up to 45 kVA, with higher capacities available through customized design.
Smart management: A 10.1-inch touchscreenand web-based platform provide centralized system monitoring.
Secure access: Supports face recognition, IC card, password, and fingerprint access.
Each solution is configured according to project load, cooling demand, backup time, cabinet quantity, and monitoring requirements.
Applications
Government
Finance
IT
Education
Transportation
Broadcasting
Medical
Energy
Data Parameters
Technical Specifications
| System | |
| Model | AC5000 |
| Cabinet Quantity | 1–15 cabinets |
| Power Grid System | Single phase: 220VAC, 50Hz, 1Ph + N + PE; Three phase: 380VAC, 50Hz, 3Ph + N + PE |
| Ambient Temperature | 0–45°C |
| Protection Level | IP20 |
| Cabinet | |
| Dimensions (W × D × H) | 600 × L × 2000 mm, with wheels |
| Display | 10-inch touch LCD |
| Lighting | LED lighting + RGB |
| Cable Entry | Top and bottom |
| Access Control | Fingerprint + IC card + face ID |
| Emergency Cooling | Pop-up door |
| Power Distribution Module | |
| Input Current | 63–200A |
| Surge Protection | Class C SPD |
| UPS System | |
| UPS Capacity | 3–10kVA / 20kVA / 120kVA |
| Input | 1P: 220VAC, 50Hz, 1P + N + PE; 3P: 380VAC, 50Hz, 3P + N + PE |
| Operating Configuration | 1P/1P, 3P/1P, 3P/3P |
| Battery | Battery packs or battery cabinets |
| PDU | |
| Configuration | 13 × IEC C13 + 3 × IEC C19, or customized |
| Cooling System | |
| Cooling Capacity | 3.5–25kW |
| Installation | Rack mounted or in-row |
| Ventilation | Back-to-front airflow |
| Compressor | Variable frequency |
| Intelligent Monitoring | |
| Monitoring Interface | Integrated intelligent monitoring screen |
| Power Monitoring | UPS and load monitoring |
| Smoke Detection | Smoke sensor |
| Environmental Monitoring | Temperature and humidity sensor, optional |
| Water Leakage | Water leakage sensor |
| Optional Security | Network camera and infrared sensor |
| Alarm Options | SMS alarm and acoustic-optic alarm |
