PodAir Series Rack Mounted Precision Cooling
PodAir Series is a compact rack-mounted precision cooling solution designed for single cabinets, server racks, communication equipment, edge facilities, and other space-constrained IT environments.
Flexible capacity: Split-type and integrated models provide 3.7–12.8 kWcooling capacity in compact 6U–12Urack-mounted formats.
Close-coupled cooling: The unit installs directly inside or close to the equipment rack, delivering cooling near the heat source and reducing unnecessary room-level airflow.
Variable-frequency efficiency: A DC inverter compressor, EC fan, electronic expansion valve, and V-shaped evaporator continuously adjust cooling output according to the actual equipment load.
Easy deployment: The pull-out rack-mounted design supports fast installation, maintenance, cabinet expansion, and automatic startup after mains power is restored.
Remote management: A standard RS485 interface supports remote monitoring and control for unattended or distributed equipment environments.
Final model selection depends on rack heat load, available rack space, power supply, outdoor-unit arrangement, installation environment, and system configuration.
Applications
Data Parameters
| Indoor Unit Model | 003 (split type) | 007 (split type) | 012 (split type) | 003 (integrated) |
|---|---|---|---|---|
| Total Cooling Capacity (kW) | 3.5 | 7.5 | 12.5 | 3.5 |
| Sensible Heat Ratio (%) | 100 | |||
| Air Volume (m³/h) | 700 | 1500 | 2300 | 700 |
| Expansion Valve Type | Electronic Expansion Valve | |||
| Fan Type | EC Fan | |||
| Compressor Type | DC Frequency Conversion | |||
| Evaporator Type | V-shaped | |||
| Refrigerant Type | R410A | |||
| PTC Heating Capacity (kW) | 1.2 | 2.4 | 3 | 1.2 |
| Humidification Capacity (kg/h) - Optional | 0.6 | 1.2 | 1.5 | / |
| Input Power | 220V (single-phase) / 50Hz | |||
| Max. Operation Current (A) | 13.5 | 26.8 | 30.5 | 13.5 |
| Weight (kg) | 22 | 38 | 47 | 45 |
| Dimensions: W × D × H (mm) | 483 × 750 × 175 (4U) | 483 × 750 × 353 (8U) | 483 × 800 × 442 (10U) | 440 × 900 × 355 (8U) |
| Outdoor Unit | ||||
| Model (Nominal Conditions) | FA006APM | FA012APM | FA018APM | (No separate outdoor unit) |
| Operation Temperature | -15~45℃ | / | ||
| Input Power | 220V (single-phase) / 50Hz | / | ||
| Current (Full Load) | 7.2 | 14.8 | 18.0 | / |
| Unit Weight (kg) | 35 | 45 | 65 | / |
| Dimensions: W × L × H (mm) | 898 × 340 × 606 | 935 × 396 × 800 | 988 × 440 × 1257 | / |
